ADI CHT ROTAX VERSION 32-300F

Low and High temp alarms can be set over the entire range of the instrument/sender. When activated, the built-in 85 dB alarm will sound and the display will flash. The alarm can be enabled or disabled with a single key press. Five levels of backlighting can be selected. Then all setup, calibration constants, alarm values, sender type and lighting levels selected are saved to nonvolatile memory.

Terminal C can be programmed as an External Alarm output. This could be used in conjunction with ER-1A electronic relay to control optional equipment such as an electric radiator cooling fan, or to simply activate a warning/annunciator light on your panel.

Specifications

• Power Supply: 9.5-33.0 VDC (.018 amp nominal)
• Operating Temp: 32-122F(0-50C)
• Size/ Weight: 2.475" square, low profile...easily stackable bezel, with standard aviation 2.250" raised round ring. Standard 2.625" diameter mounting hole layout at 45 degrees. Proprietary unique bezel design allows user the option of either front or rear mounting our gauges in their panel. Gauge depth behind panel: surface mounted approx. 2.60", rear mounted, approx. 2.90". Weight approx 2.3oz.
• Accuracy: Better than +/-1 digit, front panel adjustable calibration.
• Senders: Built-in calibration curves for most 15-250 ohm oil/water temperature senders such as VDO, Teleflex, Stewart-Warner, and others.
• Alarms: LOW and HIGH alarms user settable from 32-300 F.
• Display: 3 digit, degrees in Farenheit or Celsius, Five levels of backlighting.
• Output: Terminal C is Factory preset, and can be used as an External Alarm signal to control an ER-1A or a panel warning light.
