Whelen Orion 600 12V Wingtip Pta Red OR6001R

• Whelen# 01-0771733-02
• Model# OR6001R
• Description: Orion Wingtip PTA
• Color Red
• Voltage 12V

ORION600 Series of FAA/TSO approved LED aviation lighting. Incorporating the latest state of the art LED Technology available in an all-inclusive package, the ORION600 series eliminates the need for external flasher boxes. Flush mountable for a wide variety of applications with minimal integration and easily retrofitable to the Whelen legacy strobe products. The ORION600 series is quite simply the brightest form of LED Anti-collision and Position lighting available.

Model ORION600 Position/Anti-Collision Lighthead All LED self-contained wingtip mounted Position/Anti-Collision system. Eliminates the need for external power supplies and reduces current draw and provides thousands of hours of operation.

FAA TSO-C96c Class II / TSO-C30c Type II & III

• Fully FAA/TSO-C96a & TSO-C30c approved
• FAR SPEC Certified
• Replaceable hard coated polycarbonate lens to maintain maximum light output
• No RF emissions
• Aerodynamic design without sacrificing light output
• Exceeds FAA minimum intensity requirements for maximum visibility and increased safety of flight
• Environmentally tested and certified to RTCA/DO-160G standards

• Weight 0.4 lbs.(181gm)
• Dimensions H x W x L 2.04” (52mm) x 1.78” (45mm) x 5.65” (144mm)
• Volts 12 VDC 28 VDC
• Position LED colors Aviation Red Aviation Green
• Anti-Collision LED color Aviation White
• Lenses Clear Polycarbonate Hardcoat, Field Replaceable

• Product Brochure (PDF) - Includes Technical Info and Drawing

• A Technical Standard Order (TSO) is a minimum performance standard and does equal compliance with the applicable Federal Aviation Regulations. In fact other manufacturers produce TSO approved items with operational characteristics that conflict with the FARs. Whelen designs products as FAR-SPEC, Federal Aviation Regulations – Specified Lighting. FAR-SPEC is compliant with all applicable FAR’s making your installation legal.
• Installers must follow the approved guidance for installation of the product to be FAR-SPEC compliant

What is the average current draw of the Whelen Orion 600 at 12 volts and at 24 volts?
For position light: 12v = 1/2 amp, 24v = 0.17 amp
For anti-collision light: 12v = 1 amp, 24v = 1/2 amp

Are these lights priced and sold individually or as a pair?
These Orion 600 lights are priced and sold each. An order for quantity 1 will ship with 1 light.

What is the difference between the Whelen Orion 600 series and the Orion 650 series of lights?
Per the supplier: The Orion 600 series has a rear position light built into it. The footprint is also different. The Orion 650 is designed to replace our legacy A650 products while the Orion 600 is designed to replace the A600 Series assemblies.
