Maxpulse Land Lght Control STCD

Dual Circuit 12-35 VDC 0-10 a Control 500 Watts in a 1-1/4 inch Diameter Package. MaxPulse the Complete Compact, Light Weight, Powerful, Solid State Landing Light Control/Pulser! Download the Pulse Brochure in PDF.

MAXPULSE LAND LIGHT CONTROL
STC'D PN 11-06998

The MaxPulse is a solid state landing light controller. The small size and one ounce weight places this controller in a class of its own. Extreme long life, low temperature operation, high current capability, noise free operation and small size makes it a ideal landing light controller for all aircraft. This new STC version sports eight functional pulse, flash and steady state modes of operation. It is also an ideal replacement for old technology controllers requiring large heavy heat sinks and or noisy relays as part of the installation.

• Aircraft Landing Light Pulser
• No outboard heat sinks, rheostats, or other packages
• STC, PMA, RTCA/DO-160E SEC 21: qualified
• Configure for Wig Wag or Wing and taxi light pulsing
• Reduce bird strike possibilities
• Increased safety for your passengers and yourself
• Hundreds of DC Lighting Applications
• Emergency Vehicles
• Assembled in the USA

• Voltage Range: 12 to 35VDC
• Max Current: 10 Amps per Circuit
• Two Circuits
• Capacity for each Circuit:
• 120 Watts @12VDC per circuit - 240 Watts Total
• 240 Watts @24VDC per circuit - 480 Watts Total
• 280 Watts @28VDC per circuit - 560 Watts Total
• 350 Watts @35VDC per circuit - 700 Watts Total
• MaxPulse Function Modes: Switch Positions
• X Both Circuits Off
• S Starboard (right) on only
• P Port (left) on only
• S+P Both circuits On
• A44 Alternate 44 PPM (STD)
• B44 Both Flash 44 PPM
• A88 Alternate 88 PPM
• A120 Alternate 120 PPM
• Operating Temperature Range: -20° C to +50° C
• Internal Temperature Protect: +85°
• Storage Temperature: -40° C to +100° C
• Maximum Internal Temperature: @10 A +25° C above Ambient.
• Enclosure Material: Bayer FR110 resin Meets UL 94
• Flame Rating: V-2 (0.03in) V-0 (0.059in) 5VB (0.098in) 5VA (0.13in)
• FAA STC/PMA Approved
• RTCA/DO-160E Qualified
• One Year limited warranty
• Weight: 1oz (28g)
